Product Details:
Payment & Shipping Terms:
|
| Product Name: | Quick-Connect Coupling | Application: | General Pneumatics |
|---|---|---|---|
| Standard: | NPT | Nominal: | 1/4 |
| Type: | Coupling | Flow: | 32scfm |
| Material: | Brass | Technics: | Forged,Casting,Machining Air Hose Quick Coupling,Plastic Injection,Machining |
| Highlight: | NPT Pneumatic Quick Coupling,0.25in Pneumatic Quick Coupling,IATF 16949 hydraulic quick connect couplings |
||
High flow, automatic Quick-Connect Couplings designed for use with compressed air Pneumatic Quick Coupling
CB-12 Series High flow, automatic Quick-Connect Couplings designed for use with compressed air.
Applications & Markets
• General Pneumatics
• Air Tools
• Construction
Standard Materials
Features
| Body Size | PARTNO. | Thread | A | B | HEX |
| 1/4" | CB-S2B-12MN-G | 1/4-18 | 2.23 | 0.94 | 0.81 |
| 1/4" | CB-S2B-12MG-G | 1/4-19 | 2.23 | 0.94 | 0.81 |
| 1/4" | CB-S3B-12MN-G | 3/8-18 | 2.23 | 0.94 | 0.81 |
| 1/4" | CB-S3B-12MG-G | 3/8-19 | 2.23 | 0.94 | 0.81 |
| 1/4" | CB-S4B-12MG-G | 1/2-14 | 2.23 | 0.94 | 0.88 |
| Body Size | PARTNO. | Thread | C | D | HEX |
| 1/4" | CB-P1S-12MN | 1/8-27 | 1.59 | 0.58 | 0.50 |
| 1/4" | CB-P2S-12MN | 1/4-18 | 1.75 | 0.65 | 0.56 |
| 1/4" | CB-P3S-12MN | 3/8-18 | 1.75 | 0.79 | 0.69 |
| 1/4" | CB-P2B-12MN | 1/4-18 | 1.75 | 0.64 | 0.56 |
| 1/4" | CB-P2L-12MN | 1/4-18 | 1.75 | 0.65 | 0.56 |
Our Services:
| 1. Customized design, OEM is available. |
| 2. In-time & professional after sales service. |
| 3. Low MOQ, standard package, fast delivery. |
| 4. Special discount and protection are provided to our distributors. |
| 5. As an honest seller, we always use superior raw material, advanced equipments, skilled technicians and strict quality control to ensure our products to be finished in high quality and stable feature. |
